A3SS-XT11 Low profile paper HPC systems(High pressure coolant&Filtraion systems) paper tape plus magnetic separation filter combination, suitable for powdered chip conditions,such as cast iron parts processing,grinding parts processing.It can be applied to crankshaft grinding machine,gear grinding machine,etc. CJC3SS-XT11 paper tape automatic winding function,paper tape exhaustion alarm function,no coolant alarm function,paper tape accuracy can also be selected according to the working condition.
Typical application scenario
It is suitable for filtering coolant/oil in metal grinding or other processing, especially having a significant effect on magnetic powder-like processing impurities, and is also applicable to other CNC rough and finish processing conditions.
Scenario of main parameter
| Tank volume | 1800×750×280mm(350L) | Pressure regulator type | Two-position three-way valve/Plate pressure regulator/Proportional valve |
| Bulk volume | 2050×870×1090mm | Filter combination | Magnetic separator + Paper bag filter |
| Screw pump installation method | Vertical type | Filtration accuracy | 15μm – 50μm |
| Lift pump parameter | Flow 4m³/h Head 32m | Control mode | Integrated PLC/AKP module/Terminal box |
Selection Guide
To provide a more suitable pump, we need to understand as much detailed information as possible. You can request the working condition survey form from me. If you are replacing an existing pump, you can provide me with the original product model or nameplate.
